| Products name | 806-960MHz dipole antenna |
| Electric Specification | |
| Model NO. | D205112 |
| Frequency range-MHz | 806-960 |
| Band width-MHz | 154 |
| Gain -dBi | 5 |
| Horizontal beam width -° | 360 |
| Vertical beam width -° | 18 |
| VSWR | ≤2.0 |
| Input impedance-Ω | 50 |
| Polarization | Vertical |
| Max power-W | 100 |
| Connector | N-Female |
| Mechanical Specification | |
| Dimensions -mm | Φ20X800 |
| Weight -Kg | 1.2 |
